Average rating: 4.4 out of 5
View All Autel Products
Battery Tester and Diagnostic Scan Tools

Autel MaxiBAS BT609 Wireless Battery and Vehicle Diagnostic Automotive Tool

Availability: In Stock
  • Vendor:Autel

Important Shipping Information:-
• Orders received on Fridays after 11am EST will be processed the next business day
All orders shipped to a RESIDENTIAL ADDRESS will be subject to Additional charges from all carriers at this time.

Financing From Low As $21 per Month

- Instant Approval
- No hard credit pull
- $500-$20,000

Autel MaxiBAS BT608 Battery and Vehicle Diagnostic Automotive Tool.

Part Number: BT608

The MaxiBAS BT609 wireless battery and diagnostics system applies Adaptive Conductance, an advanced battery analysis method that produces a more accurate examination of the battery’s cold cranking ability and reserve capacity, vital to determining a battery’s true health. The 7-inch Android touchscreen tablet can display a quick health status of the existing battery, register a new battery and perform advanced battery and electrical system diagnostics. The BT609’s features include AutoVIN to immediately identify vehicle and battery information and to display graphic instructions for battery positioning and testing. Features service menu. Read/Clear codes on all available vehicle systems and perform common maintenance services. Print or share customized reports via Wi-Fi.

There is no better multifunctional scan tool on the market and number 1 in diagnostic automotive tools.


  • Support in-vehicle and out-of-vehicle testing of passenger vehicle batteries
  • Test 6- and 12-volt batteries: 100 – 3000 CCA
  • Test 12- and 24-volt cranking/charging systems
  • Test Flooded, AGM, AGM Spiral, EFB and GEL batteries
  • Compatible with CCA, CA, SAE, EN, IEC, DIN, JIS and MCA
  • Quick display of battery specifications through battery barcode scan, auto and manual VIN entry
  • Illustration instruction guides for battery positioning and testing
  • Read and erase codes and view Live Data of all available systems
  • Support maintenance services
Item Description
Operating System Android 9.0
Memory 2GB RAM & 64GB On-board   Memory
Display 7.0 inch TFT-LCD   with 1280 x 800 resolution & capacitive touch screen
Connectivity l   Wi-Fi (IEEE 802.11 a/b/g/n/ac   1x1)
l   BT 5.0+EDR+BLE
l   USB 2.0 (1 USB HOST + 1 USB   OTG)
l   Micro SD Card (Support up to 128GB)
Camera 8 Megapixel
Sensor Ambient Light Sensor (ALS)
Audio l   Microphone
Input/Output l   Loudspeaker
Power and Battery l   5800 mAh 3.85 V   lithium-polymer battery
l   Charging via 5 V AC/DC power   supply with the temperature between 0°C and 45°C
Input Voltage 5 V / 2 A Adapter
Operating Temp. 0 to 50° C (32 to 122° F)
Storage Temp. -10 to 60° C (14 to   140° F)
Dimensions (WxHxD) 197 mm (7.75")   x 135 mm (5.31") x 14 mm (0.55")
Weight 445   g (0.98 lb.)

View our website  www.repquip.com  for other New and Used Equipment we sell.

Review our full Shipping Terms and Conditions.
For all other shipping requests, call or e-mail us.

E-mail: support@repquip.com
Hours:  Mon to Fri 9am to 5pm EST
TEL: 1 855 320 7276

Autel MaxiBAS BT609/BT608/BT508/BT506
